 | Electrical specifications
| Model |
RAO2-10GH-60
|
| Operating frequency band, MHz |
1710-1880
|
| Gain,dBi |
10
|
| VSWR, not more than |
1.5
|
| Polarization |
vertical
|
| Max. power input, W |
50
|
| Sector in H-plane (-3 dB) |
60°
|
| Sector in E-plane (-3 dB) |
36°
|
| Impedance, Ohm |
50
|
Mechanical specifications
| Model |
RAO2-10GH-60
|
| Dimensions (LxWxH), mm |
204Ñ…63Ñ…518
|
| Weight, kg |
1,3
|
| Rated wind velocity, m/s |
55
|
| Radiator |
PCB
|
| Radome |
grey, ABS
|
| Mounting |
on a wall or on a mast (max.diam.35 mm) with CP-55U
|
| Connector |
N-female on a cables
|
| |
| |
|
 |
