 | | Electrical specifications
| Model |
PS2-4G
|
| Operating frequency band, MHz |
820-970
|
| Insertion loss (adjustable) not more, dB |
0,6
|
| Max. frequency bandwidth, MHz |
15
|
| Impedance, Ohm |
50
|
| Gain |
see figure
|
| VSWR, not more than |
1,3
|
| Input power, W |
not more than 300
|
| Temperature range, °C |
-40 to +60
|
|
|
Mechanical specifications
| Model |
PS2-4G
|
| Diameter, mm (ins.) |
50 (2")
|
| Weight, kg |
0,9
|
| Connector |
N-female
|
| Mount to 19-inch rack |
optional
|
| Length/Width/Depth not more, mm |
280x90x55
|
| |
Typical gain-frequency characteristics PS2-4G
| |
|
 |
